Atlas Air Force AF7 80 Gallon 2-Stage Air Compressor | 5 HP Low RPM | Magnetic Starter | 220V Single Phase | 175 PSI
The Atlas Air Force AF7 is a commercial-grade two-stage air compressor engineered for automotive repair facilities, fabrication shops, manufacturing plants, and industrial service centers that require dependable high-pressure compressed air. Equipped with a heavy-duty 5 HP low-RPM motor, a rugged three-cylinder cast iron two-stage pump, and an American-made 80-gallon ASME vertical tank, the AF7 delivers exceptional airflow while promoting long service life and quiet operation.
Operating between 145 and 175 PSI, the AF7 produces up to 18.5 CFM at 145 PSI and 14.5 CFM at 175 PSI, making it ideal for demanding pneumatic equipment, shop air systems, spray finishing, fabrication tools, and commercial service applications. The low-speed motor minimizes wear while maintaining consistent performance throughout the compressor's operating range.
A standout feature of the AF7 is its factory-installed magnetic starter, which controls electrical input to the motor and helps protect critical electrical components during startup and operation. Combined with premium features including vibration isolation pads, a finned tank inlet tube for moisture reduction, a hands-free tank drain extension, and a heavy-duty metal belt guard, the AF7 provides reliable performance with simplified maintenance for years of dependable service.
Key Features
- Commercial-grade belt-driven reciprocating air compressor.
- Heavy-duty 5 HP low-RPM electric motor.
- Three-cylinder cast iron two-stage compressor pump.
- Factory-installed magnetic starter extends motor and electrical component life.
- 80-gallon vertical ASME air tank made in the USA.
- Produces up to 175 PSI operating pressure.
- Delivers 18.5 CFM at 145 PSI.
- Delivers 14.5 CFM at 175 PSI.
- Extremely quiet operation.
- Premium vibration isolation pads included.
- Hands-free tank drain extension for easy maintenance.
- Finned inlet tube helps reduce moisture accumulation inside the tank.
- Heavy-duty metal belt guard.
- 1/2-inch NPT air outlet with ball valve included.
- Designed for continuous commercial shop use.
- 1-Year Parts Only Warranty.
Ideal Applications
- Automotive repair facilities
- Commercial garages
- Fabrication shops
- Machine shops
- Industrial maintenance
- Manufacturing facilities
- Fleet maintenance operations
- Pneumatic air tool systems
- Spray painting
- General shop compressed air systems
Specifications
| Brand | Atlas Air Force |
| Model | AF7 |
| Compressor Type | Commercial Belt-Driven Vertical Air Compressor |
| Pump Design | Three-Cylinder Cast Iron Two-Stage |
| Motor Output | 5 HP Low-RPM Motor |
| Tank Capacity | 80 Gallon Vertical ASME Tank (Made in USA) |
| Maximum Pressure | 175 PSI |
| Operating Pressure Range | 145–175 PSI |
| Air Delivery @ 145 PSI | 18.5 CFM |
| Air Delivery @ 175 PSI | 14.5 CFM |
| Air Outlet | 1/2" NPT with Ball Valve Included |
| Magnetic Starter | Included |
| Electrical Requirement | 220 Volt, Single Phase, 30 Amp Breaker, 10 Gauge Wire Required |
| Overall Dimensions | 36" L × 24" W × 69" H |
| Pump Construction | Three-Cylinder Cast Iron Reciprocating Pump |
| Noise Reduction Features | Low RPM Motor with Vibration Isolation Pads |
| Moisture Reduction | Finned Tank Inlet Tube |
| Tank Drain | Hands-Free Drain Extension |
| Shipping Weight | 485 lb. |
| Warranty | 1-Year Parts Only Warranty |
```
